Start-Up
4.7 Commissioning
4-74
SINUMERIK 802C
6FC5 5973AA200BP2 (01.02)
Once entered, these data are immediately written to the data memory.
The machine data are activated depending on the Activation setting of the appropriate ma-
chine data, Section 4.1.2.
Note
Since these data are only stored in the memory backed up for a limited period of time, a data
backup is necessary (see Section 4.1.4).
Machine data
The following machine data list contains all general and other machine data and setting data,
which can be changed if necessary.
Number Description
Default
Value
10074 Division ratio of the PLC task factor for main run 2
11100 Number of auxiliary function groups 1
11200 Standard machine data loaded on next Power On O
H
11210 MD backup of changed MD only 0FH
11310 Threshold for direction change of handwheel 2
11320 Handwheel pulses per detent position (handwheel number): 0...1 1
20210 Maximum angle for compensation blocks with TRC 100
20700 NC-Start disable without reference point 1
21000 Circle end point monitoring constant 0.01
22000 Auxiliary function group (aux. fct. no. in channel): 0...49 1
22010 Auxiliary function type (aux. fct. no. in channel): 0...49 “”
22030 Auxiliary function value (aux. fct. no. in channel): 0...49 0
22550 New tool compensation for M function 0
Setting data
Number Explanation
Default-
Value
41110 Jog feedrate 0
41200 Spindle speed 0
42000 Start angle 0
42100 Dry run feedrate 5000
