2.12 Block descriptions
Power Line Basic PLC Program (P3)
2-108 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Addr6 : ANY ;
Unit6 : BYTE ;
Column6 : WORD ;
Line6 : WORD ;
Addr7 : ANY ;
Unit7 : BYTE ;
Column7 : WORD ;
Line7 : WORD ;
Addr8 : ANY ;
Unit8 : BYTE ;
Column8 : WORD ;
Line8 : WORD ;
FMNCNo : int;1)
END_VAR
VAR_OUTPUT
Error : BOOL ;
NDR : BOOL ;
State : WORD ;
END_VAR
VAR_IN_OUT:
RD1 : ANY ;
RD2 : ANY ;
RD3 : ANY ;
RD4 : ANY ;
RD5 : ANY ;
RD6 : ANY ;
RD7 : ANY ;
RD8 : ANY ;
END_VAR
Description of formal parameters
The table below list all formal parameters of the GET function.
Signal I/O Type Value range Remarks
Req I Bool Job start with positive signal edge
NumVar I Int 1 to 8
(corresponds to use
of Addr1 to Addr8)
Number of variables to be read
Addr1 to Addr8 I Any [DBName].[VarName
]
Variable identifiers from NC Var selector
Unit1 to Unit8 I Byte Area address, optional for variable
addressing
