Detailed Description
2.1 NC/PLC interface signals
Various NC/PLC Interface Signals and Functions (A2)
2-18 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB31, ... DBX76.0 (lubrication pulse)
Following a control POWER ON/RESET, the signal status is 0 (FALSE).
The "lubrication pulse" is inverted (edge change) as soon as the machine axis completes a
distance longer than the parameterized traversing distance for lubrication.
MD33050 $MA_LUBRICATION_DIST (distance for lubrication by PLC)
2.1.9 Signals to axis/spindle (digital drives)
DB31, ... DBX20.1 (ramp-function-generator fast stop) (not on 810D)
A "fast stop" is requested for the drive. The drive is then stopped without a ramp function
(speed setpoint 0). Servo enable is maintained.
DB31, ... DBX20.2 (torque limit 2) (not on 810D)
Request for torque limit 2. The limit value is specified in the drive parameters.
DB31, ... DBX20.3 (speed setpoint smoothing) (not on 810D)
Request to smooth the speed setpoint.
DB31, ... DBX21.0 / 21.1 / 21.2 (drive parameter set selection A, B, C)
Request to change over drive parameter set:
DBX 21.2 DBX 21.1 DBX21.0 Parameter-set number
0 0 0 1
0 0 1 2
0 1 0 3
0 1 1 4
1 0 0 5
1 0 1 6
1 1 0 7
1 1 1 8
The checkback signal is sent via:
DB31, ... DBX93.0,1 / 93.2 (active drive parameter set)
