Page #266 background image
Data Lists
5.2 Setting data
Acceleration (B2)
5-2 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Number Identifier: $MA_ Description
35240 ACCEL_TYPE_DRIVE "DRIVE" acceleration characteristic curve: ON/OFF
35242 ACCEL_REDUCTION_TYPE Type of acceleration reduction
5.2 5.2 Setting data
5.2.1 Channel-specific setting data
Number Identifier: $SC_ Description
42500 SD_MAX_PATH_ACCEL Max. path acceleration
42502 IS_SD_MAX_PATH_ACCEL Analysis of SD 42500: ON/OFF
42510 SD_MAX_PATH_JERK Max. path-related jerk
42512 IS_SD_MAX_PATH_JERK Analysis of SD 42510: ON/OFF
5.3 5.3 System variables
Identifier Description
$AC_PATHACC Path acceleration for real-time events
$AC_PATHJERK Path jerk for real-time events
