Detailed description
2.13 Signal/data descriptions
Power Line Basic PLC Program (P3)
2-254 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Addresses in DB21, ... Variable Type Initial setting Comment
DBB 261
G_FKT_GR_54
Byte 0 Active G function of group 54
DBB 262
G_FKT_GR_55
Byte 0 Active G function of group 55
DBB 263
G_FKT_GR_56
Byte 0 Active G function of group 56
DBB 264
G_FKT_GR_57
Byte 0 Active G function of group 57
G functions (values)
A full list of all G functions can be found in:
References:
/PG/ Programming Guide, Basics
2.13.4 Message signals in DB 2
General
DB 2 allows the user to display the messages for individual signals on the operator panel. As
the lists of interface signals show, signals are divided into predefined groups. When a
message occurs, disappears or is acknowledged, the number entered in the message
number column is transferred to the MMC. Text can be stored in the MMC for each message
number.
References:
/IAD/ Installation and Start-Up Guide; Message Numbers
Note
The number of user areas can be parameterized via FB 1.
After the configuration has been modified (FB 1: MsgUser), DB 2/3 must be deleted.
Channel areas in DB 2
Area Address Message number
Channel 1 DBX0.0 - DBX11.7 510.000 -- 510.231
Channel 1, geo axes DBX12.0 - DBX17.7 511.100 - 511.315
Channel 2 DBX18.0 - DBX29.7 520.000 - 520.231
Channel 2, geo axes DBX30.0 - DBX35.7 521.100 - 521.315
Channel 3 DBX36.0 - DBX47.7 530.000 - 530.231
Channel 3, geo axes DBX48.0 - DBX53.7 531.000 - 531.315
Channel 4 DBX54.0 - DBX65.7 540.000 - 540.231
Channel 4, geo axes DBX66.0 - DBX71.7 541.100 - 541.315
