Detailed description
2.13 Signal/data descriptions
Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-255
Area Address Message number
Channel 5 DBX72.0 - DBX83.7 550.000 - 550.231
Channel 5, geo axes DBX84.0 - DBX89.7 551.100 - 551.315
Channel 6 DBX90.0 - DBX101.7 560.000 - 560.231
Channel 6, geo axes DBX102.0 - DBX107.7 561.100 - 561.315
Channel 7 DBX108.0 - DBX119.7 570.000 - 570.231
Channel 7, geo axes DBX120.0 - DBX125.7 570.100 - 571.315
Channel 8 DBX126.0 - DBX137.7 580.000 - 580.231
Channel 8, geo axes DBX138.0 - DBX143.7 581.100 - 581.315
Channels 9 and 10 are not currently
implemented
User areas in DB 2
Area Address Message number
Axis/spindle 1 DBX144.0 - DBX145.7 600.100 - 600.115
Axis/spindle 2 DBX146.0 - DBX147.7 600.200 - 600.215
Axis/spindle 3 DBX148.0 - DBX149.7 600.300 - 600.315
Axis/spindle 4 DBX150.0 - DBX151.7 600.400 - 600.415
Axis/spindle 5 DBX152.0 - DBX153.7 600.500 - 600.515
Axis/spindle 6 DBX154.0 - DBX155.7 600.600 - 600.615
Axis/spindle 7 DBX156.0 - DBX157.7 600.700 - 600.715
Axis/spindle 8 DBX158.0 - DBX159.7 600.800 - 600.815
Axis/spindle 9 DBX160.0 - DBX161.7 600.900 - 600.915
Axis/spindle 10 DBX162.0 - DBX163.7 601.000 - 601.015
Axis/spindle 11 DBX164.0 - DBX165.7 601.100 - 601.115
Axis/spindle 12 DBX166.0 - DBX167.7 601.200 - 601.215
Axis/spindle 13 DBX168.0 - DBX169.7 601.300 - 601.315
Axis/spindle 14 DBX170.0 - DBX171.7 601.400 - 601.415
Axis/spindle 15 DBX172.0 - DBX173.7 601.500 - 601.515
Axis/spindle 16 DBX174.0-DBX175.7 601.600 - 601.615
Axis/spindle 17 DBX176.0 - DBX177.7 601.700 - 601.715
Axis/spindle 18 DBX178.0 - DBX179.7 601.800 - 601.815
Axes 19 to 31 are not currently
implemented
