Siemens SINUMERIK 804D sl Function Manual

Data Lists
5.2 Setting data
Travel to Fixed Stop (F1)
5-2 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5.2 5.2 Setting data
5.2.1 Axis/spindle-specific setting data
Number Identifier: $SA_ Description
43500 FIXED_STOP_SWITCH Selection of travel to fixed stop
43510 FIXED_STOP_WINDOW Clamping torque when traveling to fixed stop
extended to a torque greater than 100%
43520 FIXED_STOP_TORQUE Fixed stop monitoring window
5.3 5.3 Signals
5.3.1 Signals to axis/spindle
DB number Byte.Bit Description
31, ... 1.1 Acknowledge fixed stop reached
31, ... 1.2 Sensor for fixed stop
31, ... 1.3 Axis/spindle disable
31, ... 2.1 Controller enable
31, ... 3.1 Enable travel to fixed stop
31, ... 62.4 Activate travel to fixed end stop
31, ... 62.5 Fixed stop reached
