Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-177
Declaration of the function
STL representation
FUNCTION FC 7: void
//NAME :TM_REV
VAR_INPUT
Start: BOOL ;
ChgdRevNo: BYTE ;
END_VAR
VAR_OUTPUT
Ready: BOOL ;
Error : INT ;
END_VAR
BEGIN
END_FUNCTION
Description of formal parameters
The table below lists all formal parameters of the TM_REV function.
Signal I/O Type Value range Remarks
Start I Bool = transfer is started
ChgdRevNo I Byte 1.. Number of revolver interface
Ready Q Bool = transfer completed
Error Q Int 0..3 Error checkback
0: No error has occurred
1: No revolver present
2: Illegal revolver number in parameter "ChgdRevNo"
3: Illegal job ("interface active" signal for selected
revolver = "FALSE")
