Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
2-246 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
SW 4 and lower
Source:
MCP button
Destination:
Interface DB (Parameter ChanNo)
INC 1 ... 10 000, INC Var. DB21, ... DBB13, Bit 0 to 5
INC 1 ... 10 000, INC Var. DB21, ... DBB17, Bit 0 to 5
INC 1 ... 10 000, INC Var. DB21, ... DBB21, Bit 0 to 5
Source:
MCP button
Destination:
Interface DB (6 axis DBs)
INC 1 ... 10 000, INC Var.
(up to SW 4)
DB31, ... DBB5, Bit 0 to 5
Direction keys rapid traverse override
The transfer is dependent upon the selected axis. The corresponding interface bits are
deleted for axes that are not selected.
Source:
MCP button
Destination:
Interface DB (Parameter ChanNo)
Direction key + DB21, ... DBX12.7
Direction key - DB21, ... DBX12.6
Rapid traverse override DB21, ... DBX12.5
Direction key + DB21, ... DBX16.7
Direction key - DB21, ... DBX16.6
Rapid traverse override DB21, ... DBX16.5
Direction key + DB21, ... DBX20.7
Direction key - DB21, ... DBX20.6
Rapid traverse override DB21, ... DBX20.5
Source:
MCP button
Destination:
Interface DB (6 assigned axis DBs)
Direction key + DB31, ... DBX4.7
Direction key - DB31, ... DBX4.6
Rapid traverse override DB31, ... DBX4.5
