Detailed Description
2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-125
Parameterization:
Signal Type Value range Meaning
PIService ANY PI. TRESMO Reset monitoring values
Unit INT 1 to 10 TO area
WVar1 WORD -max ..max ToolNumber
0: Applies to all tools
>0: Applies only to this tool
<0: Applies to all sister tools of the specified T No.
WVar2 WORD 0 ... Maximum D number
>0: Monitoring of specified edge of specified tools is
reset.
0: Monitoring of all edges of specified tools is reset.
WVar3 WORD 0 ...15 Monitoring types
Type of monitoring to be reset.
This parameter is binary-coded.
1: Tool-life monitoring is reset.
2: Count monitoring is reset.
4: Wear monitoring is reset.
8: Total-offset monitoring is reset.
Combinations of monitoring types can be reset by adding
the values above.
0: All active tool-monitoring functions ($TC_TP9) are
reset.
PI service: TSEARC
Complex search using search screen forms
Function:
(dependent on parameter assignment)
The PI service allows you to search for tools with specified properties within a search domain
(in one or more magazines starting and ending at a specific location). The specified
properties refer only to data of the tools and their cutting edges. The PI service is only
available if tool management is activated. You can define a search direction and the number
of hits for the PI service (e.g., one tool for the next tool with matching properties or all tools
with the specified properties). As a result of this service, the user who made the call receives
a list of the internal T numbers of the tools found.
The search criteria can only be specified as AND operations. If an application needs to
define an OR operation for the search criteria, it must first execute a series of queries with
AND criteria and then combine/evaluate the results of the individual queries.
