Siemens SINUMERIK 804D sl Function Manual

Detailed Description
2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-127
For a symmetrical search (see parameter "SearchDirection"), the search domain must only
include one magazine (cases 2 and 5 in the table above). If another search domain is
specified, the service will malfunction. A reference location must be specified in the
parameters MagNrRef and PlaceNrRef for a symmetrical search (see parameter
"SearchDirection"). The reference location is specified in the parameters MagNrRef and
PlaceNrRef. The reference location is a buffer location (a location from the magazine buffer,
i.e., change position, gripper, etc.) or a load point (a location from the internal loading
magazine). The search is executed symmetrically with reference to the magazine location in
front of the specified reference location. A multiple assignment to the magazine being
searched must be configured in the TPM block for the reference location. If this is not the
case, a malfunction occurs. If the magazine location in front of the reference location is
outside the search domain, the service responds as if it has not found a matching location.
Note
Before and after this PI service, the MMCSEM PI service must be called up with associated
WVar1 parameters for this PI service. See PI service MMCSEM for more information.
Parameter assignment
Signal Type Value range Meaning
PIService ANY PI.TSEARC Complex search using search screen forms
Unit INT 1, 2 TOA
WVar1 INT MagNrFrom Magazine number of magazine from which
search must begin
WVar2 INT PlaceNrFrom Location number of location in magazine
MagNrFrom, at which search must begin
WVar3 INT MagNrTo Magazine number of magazine at which search
must end
WVar4 INT PlaceNrTo Location number of location in magazine
MagNrTo, at which search must end
WVar5 INT MagNrRef Magazine number of (internal) magazine, with
reference to which the symmetrical search is to be
performed. (this parameter is only relevant with a
"symmetrical" search direction)
WVar6 INT PlaceNrRef Location number of location in magazine
MagNrRef, with reference to which the symmetrical search
is to be performed. This parameter is only relevant with a
"symmetrical" search direction
WVar7 INT 1, 2, 3 SearchDirection specifies the required search direction.
1: Forwards from the first location of the search domain
2: Backwards from the last location of the search domain
3: Symmetrical with real magazine location positioned in
front of the location specified by MagNrRef and PlaceNrRef
