Detailed Description
2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
2-140 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Approvals
When one MCP is switched over to another, any active feed or axis enables will be retained.
Note
Keys actuated at the moment of switchover remain operative until the new MCP is activated
(by the HMI, which is subsequently activated). The override settings for feedrate and spindle
also remain valid. To deactivate actuated keys, the input image of the machine control
signals must be switched to non-actuated signal level on a falling edge of DB10.DBX104.0.
The override settings should remain unchanged.
Measures for deactivating keys must be implemented in the PLC user program
(see below: Example of override switchover).
The call is permitted only in cyclic program OB1.
Declaration of function
FUNKTION_BLOCK FB9
VAR_INPUT
Ack :BOOL; //Acknowledge interrupts
OPMixedMode :BOOL:= FALSE; // Mixed operation with non-M-to-N-enabled OP
deactivated
ActivEnable :BOOL:= TRUE; // Not supported
MCPEnable :BOOL:= TRUE; // Activate MCP switchover
END_VAR
VAR_OUTPUT
Alarm1 :BOOL; // Interrupt: Error in HMI bus address, bus type!
Alarm2 :BOOL; // Interrupt: No confirmation HMI 1 offline!
Alarm3 :BOOL; // Interrupt: HMI 1 is not going offline!
Alarm4 :BOOL; // Interrupt: No confirmation HMI 2 offline!
Alarm5 :BOOL; // Interrupt: HMI 2 is not going offline!
Alarm6 : BOOL ; // Interrupt: Queuing HMI is not going online!
Report : BOOL ; // Message: Sign-of-life monitoring
ErrorMMC : BOOL ; // Error detection HMI
END_VAR
