Siemens SINUMERIK 804D sl Function Manual

Detailed Description
2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
2-220 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Direction keys rapid traverse override
The transfer is dependent upon the selected axis. The corresponding interface bits are
deleted for axes that are not selected.
Source:
MCP button
Destination:
Interface DB (parameter ChanNo)
Direction key + DB21, ... DBX12.7
Direction key - DB21, ... DBX12.6
Rapid traverse override DB21, ... DBX12.5
Direction key + DB21, ... DBX16.7
Direction key - DB21, ... DBX16.6
Rapid traverse override DB21, ... DBX16.5
Direction key + DB21, ... DBX20.7
Direction key - DB21, ... DBX20.6
Rapid traverse override DB21, ... DBX20.5
Source:
MCP button
Destination:
Interface DB (6 assigned axis DBs)
Direction key + DB31, ... DBX4.7
Direction key - DB31, ... DBX4.6
Rapid traverse override DB31, ... DBX4.5
Override
Source:
MCP setting
Destination:
Interface DB (parameter ChanNo)
Feedrate override DB21, ... DBB4
Source:
MCP setting
Destination:
Interface DB (6 assigned axis DBs)
Feedrate override DB31, ... DBB0
Channel signals
Source:
MCP keys
Destination:
Interface DB (parameter ChanNo)
NC Start DB21, ... DBX7.1
NC Stop DB21, ... DBX7.3
Reset DB21, ... DBX7.7
Single block DB21, ... DBX0.4
