Detailed Description
2.2 Flat D number structure
Tool Compensation (W1)
2-20 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Direct, absolute programming
Programming in the part program is carried out as before. Only the value range of the
programmed D number is increased.
Example 1:
MD22550 $MC_TOOL_CHANGE_MODE = 0
MD18102 $MN_MM_TYPE_OF_CUTTING_EDGE = 1
MD20270 $MC_CUTTING_EDGE_DEFAULT = –1
...
D92
X0 Traverse with compensations from D92
T17 Outputs T=17 to the PLC
X1 Traverse with compensations from D92
D16
X2 Traverse with compensations from D16
D32000
X3 Traverse with compensations from D32000
T29000 Outputs T=29000 to the PLC
X4 Traverse with compensations from D32000
D1
X5 Traverse with compensations from D1
...
Example 2:
MD22550 = 0
T1
T2
T3
No wait, D777 is activated,
T3 = programmed and active tool in display
D777
D777 = programmed and active compensation
Note
The tool change and the assignment of a D compensation to an actual tool are not the
responsibility of NCK.
