Siemens SINUMERIK 804D sl Function Manual

Detailed Description
2.1 Various interface signals and functions (A2)
NC/PLC Interface Signals (Z1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-11
DB19
DBX10.1 Alarm area selection
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Alarm area selection active
Signal state 0 or
edge change 1 → 0
Alarm area selection inactive
DB19
DBX10.2 Tool offset selection
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Tool offset selection active
Signal state 0 or
edge change 1 → 0
Tool offset selection inactive
DB19
DBX10.7
ShopMill control signal
Edge evaluation: no Signal(s) updated: cyclic
DB19
DBX12.2 COM2
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
COM2 active
Signal state 0 or
edge change 1 → 0
COM2 inactive
Application
example(s)
Valid for HMI Embedded;
a file transfer can be initiated via RS-232-C.
