Detailed Description
2.1 Various interface signals and functions (A2)
NC/PLC Interface Signals (Z1)
2-38 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB31, ...
DBX20.3
Speed setpoint smoothing
Signal state 0 or
edge change
1 → 0
No smoothing of the speed setpoint value is requested by the PLC.
Application
example(s)
With this interface signal, speed setpoint smoothing can - for example - be activated from the PLC
user program for a spindle during speed control to achieve smooth torque output. Speed setpoint
smoothing can therefore be deactivated when the spindle is in positioning mode.
Special cases,
errors, ....
Corresponding to .... DB31, ... DBX92.3 (speed setpoint smoothing active)
Additional references /IAD/ SINUMERIK 840D Startup Guide; Chapter: SIMODRIVE 611D
DB31, ...
DBX21.0 - DBX21.2
Drive parameter set selection A, B, C
Edge evaluation: no Signal(s) updated: cyclic
Meaning With bit combinations A, B and C it is possible to select 8 different drive parameter sets for the
digital drives SIMODRIVE 611D/611U/SINUMERIK 810D.
The following assignment applies:
'ULYHSDUDPHWHUVHW
&
%
$
The switchable drive parameters are as follows:
• Current setpoint filters (low-pass, band-stop); for adaptation to the mechanics
• Motor speed normalization
• Speed controller parameters
• Speed setpoint filter
• Speed monitoring data
As soon as the new drive parameter becomes effective, the drive signals this to the PLC using the
interface signals:
DB31, ... DBX93.0, 1 and 2 (active parameter set).
