Page #1923 background imageLoading...
Page #1923 background image
Detailed Description
2.1 Various interface signals and functions (A2)
NC/PLC Interface Signals (Z1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-59
DB31, ...
DBX94.3
|M
d
| < M
dx
Corresponding to .... DB31, ... DBX94.2 (ramp-up completed)
MD1428 $MD_TORQUE_THRESHOLD_X
MD1429 $MD_TORQUE_THRESHOLD_X_DELAY
MD1427 $MD_SPEED_DES_EQ_ACT_DELAY
Additional references /IAD/ SINUMERIK 840D Installation and Startup Guide; Chapter: SIMODRIVE 611D
or
/IAG/ SINUMERIK 810D Installation and Start-up Guide
DB31, ...
DBX94.4
|n
act
| < n
min
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The SIMODRIVE 611 D/ 611D signals the PLC that the speed actual value n
act
is less than the
minimum speed (n
min
).
The minimum speed is defined using the machine data:
MD1418 $MD_SPEED_THRESHOLD_MIN.
Signal state 0 or
edge change
1 → 0
The speed actual value is higher than the minimum speed.
Corresponding to .... MD1418 $MD_SPEED_THRESHOLD_MIN (minimum speed (n
min
for n
act
< n
min
))
Additional references /IAD/ SINUMERIK 840D Installation and Startup Guide; Chapter: SIMODRIVE 611D
or
/IAG/ SINUMERIK 810D Installation and Start-up Guide
DB31, ...
DBX93.5
|n
act
| < n
x
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The 611D/ 611U signals the PLC that the speed actual value n
act
is less than the threshold speed
(n
x
).
The threshold speed is defined using the machine data:
MD1417 $MD_SPEED_THRESHOLD_X.
Signal state 0 or
edge change
1 → 0
The speed actual value is higher than the threshold speed.
Corresponding to .... MD1417 $MD_SPEED_THRESHOLD_X (threshold speed (n
x
for n
act
< n
x
))
Additional references /IAD/ SINUMERIK 840D Installation and Startup Guide; Chapter: SIMODRIVE 611D
or
/IAG/ SINUMERIK 810D Installation and Start-up Guide
