Detailed Description
2.7 Program operation mode
Mode Group, Channel, Program Operation, Reset Response (K1)
2-114 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
10 Program continuation during Teach In or after Teach In deactivation
Continuation: With system ASUB RET
11 Overstore selection
Continuation: With system ASUB REPOS
12 Alarm with reaction correction block with REPOS
Continuation: With system ASUB REPOS
13 Retraction motion with G33 and stop
Continuation: With system ASUB RET
14 Activation of dry run feedrate
Continuation: With system ASUB REPOS
15 Deactivation of dry run feedrate
Continuation: With system ASUB REPOS
16 Activation of skip block
Continuation: With system ASUB REPOS
17 Deactivation of skip block
Continuation: With system ASUB REPOS
18 Activate machine data
Continuation: With system ASUB REPOS
19 Activate user data
Continuation: With system ASUB REPOS
User routine protection level
If a userdefined routine is to be used, i.e., if a value other than 0 is in MD 11610:
ASUP_EDITABLE, a protection level can be defined for userspecific routine _N_ASUP_SPF.
The protection level can be set to values between 0 and 7 and must be entered in MD11612
$MN_ASUB_EDIT_PROTECTION_LEVEL. For further information about protection levels,
refer to:
References: /IAD/, Installation and Start-Up Guide, Protection Level Concept
Single-block processing
Bit 0 in machine data MD10702 $MN_IGNORE_SINGLEBLOCK_MASK determines whether
internal ASUBs or the described user ASUBs are to be executed without interruption after
every block even when single-block processing is selected:
Bit 0 set: Internal ASUBs are not stopped in any block.
Bit 0 not set Internal ASUBs are stopped in every block.
Danger
The machine manufacturer is responsible for the contents of ASUB routines used to replace
ASUP.SYF supplied by Siemens.
