Detailed Description
2.9 Program control
Mode Group, Channel, Program Operation, Reset Response (K1)
2-130 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
• The following rule applies to Spindle programming via S, M3, M4, M5, M41 - M45 and
M70 (or MD 20094: SPIND_RIGID_TAPPING_M_NR) with reference to the address
extension:
If an address extension was programmed, it is also resolved.
If several spindles were configured, the address extension is always output as well.
If no address extension was programmed, the number of the master spindle is inserted
(S<spindle_number>=).
• Indirect G code programming in form G[ <group> ] = <printout> is substituted by the
corresponding G code.
Original block: Display block:
N510 R1=2
N520 G[8]= R1 N520 G54
• Modal G codes that do not generate an executable block are collected and output with
the display block of the next executable block if permitted by the syntax (DIN block). If
this is not the case (e.g., predefined subroutine call TRANSMIT), a separate display block
containing the modified G codes is placed in front of the next executable block.
Original block: Display block:
N610 G64 G64
N620 TRANSMIT N620 TRANSMIT
• A display block is always generated for part program lines in which the addresses
F and FA appear
(including for MD22240 $MC_AUXFU_F_SYNC_TYPE = 3).
Original block: Display block:
N630 F1000 N630 F1000
N640 X100 N640 X100
• The display blocks generated for the block display are derived directly from the
programmed part program blocks. If intermediate blocks (e.g., tool radius compensation
G41/G42, radius/chamfer RNDM, RND, CHF, CHR) are generated in the course of
contour preprocessing, these are assigned the display information from the part program
block on which the motion is based.
Original block: Display block:
N710 Y157.5 G42 N710 Y157.5 G42
N720 Z-67.5 RND=7.5 N720 Z-67.5 RND=7.5
