2.10 System settings for power-up, RESET/part-program end and part-program start
Mode Group, Channel, Program Operation, Reset Response (K1)
2-140 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Table 2-15 Effect of MD20110 $MC_RESET_MODE_MASK Bits 13 to 17 (in SW 6.4 and higher, Bit 16 to Bit 17)
Bit 13 = 1 Bit 14 = 1 Bit 15 = 1 Bit 16 = 1 Bit 17 = 1
Active guide value
coupling is
retained.
The current setting
of the basic frame
is retained.
The active
electronic gears
are deactivated.
The current setting
of the master
spindle is retained.
The current setting
of the master tool
holder is retained.
Bit 13 = 0 Bit 14 = 0 Bit 15 = 0 Bit 16 = 0 Bit 17 = 0
Guide value
coupling is
separated.
Basic frame is
deselected.
The active
electronic gears
are retained.
Initial setting for
the master spindle
according to
MD20090.
Initial setting for
the master tool
holder according
to MD20124.
RESET response of master spindle
Up to SW 6.3 the master spindle setting was reset to the configured value on M30/RESET.
Depending on the setting of Bit 0 of MD20110 $MC_RESET_MODE_MASK, there are two
cases:
Bit 0 = 0:
No Init blocks are generated. (default: the current settings are retained)
Bit 0 = 1:
Init blocks are generated. The settings activated by RESET become valid.
MD20152 $MC_GCODE_RESET_MODE
In SW 5 and higher, MD20152 $MC_GCODE_RESET_MODE replaces Bits 4 and 5 from
MD20110 $MC_RESET_MODE_MASK. In addition, the setting options are expanded:
Up to and including SW 4
the following applies to Bits 4 and 5 of MD20110 $MC_RESET_MODE_MASK:
Bit 4: Level control
Bit 5: Control of settable frames
Each G code group controlled in MD20150 $MC_GCODE_RESET_VALUES[i] can be
selectively controlled with the additional MD20152 $MC_GCODE_RESET_MODE[i].
MD20152 $MC_GCODE_RESET_MODE[i]
(i = G code group -1)
0 1
MD20150 $MC_GCODE_RESET_VALUES[i] The value stored in
MD20150 is active
The last active/
current value is active
