Siemens SINUMERIK 804D sl Function Manual

Detailed Description
2.3 Coordinate systems
Axis Types, Coordinate Systems, Frames (K2)
2-36 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Manual traverse in SZS
The geometry axes are traversed in the WCS in JOG mode. It is also possible to carry out
manual traversing in the SZS coordinate system. Using variable $AC_JOG_COORD it is
possible to switch between manual traverse in the WCS or SZS.
3B3)5$0(
[
\
\
[
3B&<&)5$0(
:&6
6=6
Fig. 2-23 Manual traverse in WCS or SZS
