Detailed description
2.11 Supplementary conditions and NC VAR selector
Power Line Basic PLC Program (P3)
2-78 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Minimum Recommendation
Processor 80486 Pentium
RAM (MB) 32 Or more
Hard disk,
free capacity (MB)
200 > 400
Interfaces MPI incl. cable
Memory card
Graphics VGA or TIGA SVGA
Mouse yes
Operating system Windows 95/98/NT
STEP 7 and higher
Version 4
Windows 95/98/NT
or higher
STEP 7 and higher
Version 5.1
The STEP7 package for the S7300 can be obtained and installed on equipment meeting the
above requirements in cases where the package has not already been supplied with the
programming device.
The following functions are possible with this package:
Programming
Editors and compilers for STL (complete scope of the language incl. SFB/SFC calls),
LAD, FBD
Creation and editing of assignment lists (symbol editor)
Data block editor
Input and output of blocks ON/OFF line
Insertion of modifications and additions ON and OFF line
Transfer of blocks from programming device to the PLC and vice versa
Parameterizing
Parameterizing tool HW Config for CPU and I/O device parameterization
Communication Configuration configuration tool for setting the CPU communication
parameters
Output of system data such as hardware and software version, memory capacity, I/O
expansion/assignment
Testing and diagnostics (ONLINE)
Variable status/forcing (I/Os, flags, data block contents, etc.)
Status of individual blocks
Display of system states (ISTACK, BSTACK, system status list)
Display of system messages
PLC STOP/complete restart/overall reset triggering from the programming device
Compress PLC
