Subroutines, Macros
2.16 Suppress individual block (SBLOF, SBLON)
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
2-33
Example: cycle is to act like a command for a user
Main program
N10 G1 X10 G90 F200
N20 X-4 Y6
N30 CYCLE1
N40 G1 X0
N50 M30
Program cycle:1
N100 PROC CYCLE1 DISPLOF SBLOF ;Suppress single block
N110 R10=3*SIN(R20)+5
N120 IF (R11 <= 0)
N130 SETAL(61000)
N140 ENDIF
N150 G1 G91 Z=R10 F=R11
N160 M17
CYCLE1 is processed for an active single block, i.e., the Start key must be pressed once for
machining with CYCLE1.
Example: an ASUP, which is started by the PLC in order to activate a modified zero offset and tool
offsets, is to be executed invisibly.
N100 PROC ZO SBLOF DISPLOF
N110 CASE $P_UIFRNUM OF 0 GOTOF _G500
-->1 GOTOF _G54 2 GOTOF _G55 3
-->GOTOF _G56 4 GOTOF _G57
-->DEFAULT GOTOF END
N120 _G54: G54 D=$P_TOOL T=$P_TOOLNO
N130 RET
N140 _G54: G55 D=$P_TOOL T=$P_TOOLNO
N150 RET
N160 _G56: G56 D=$P_TOOL T=$P_TOOLNO
N170 RET
N180 _G57: G57 D=$P_TOOL T=$P_TOOLNO
N190 RET
N200 END: D=$P_TOOL T=$P_TOOLNO
N210 RET
