Motion synchronous actions
10.4 Actions in synchronized actions
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
10-23
$AC_SPLITBLOCK
Value: Meaning:
0 Unchanged programmed block (a block generated by the compressor is also
dealt with as a programmed block)
1 There is an internally generated block or a shortened original block
3 The last block in a chain of internally generated blocks or shortened original
blocks is available
Example of counting corner rounding blocks
$AC_MARKER[0]=0
$AC_MARKER[1]=0
$AC_MARKER[2]=0
...
;Definition of synchronized actions with which
;corner rounding blocks are counted
;All corner rounding blocks count in $AC_MARKER[0]
ID = 1 WHENEVER ($AC_TIMEC ==0) AND ($AC_BLOCKTYPE==5) DO _
$AC_MARKER[0]= $AC_MARKER[0] + 1
...
;All corner rounding blocks generated with G641 count in $AC_MARKER[1]
ID = 2 WHENEVER ($AC_TIMEC ==0) AND ($AC_BLOCKTYPEINFO==5001) DO _
$AC_MARKER[1]= $AC_MARKER[1] + 1
...
;All corner rounding blocks generated with G642 count in $AC_MARKER[2]
ID = 3 WHENEVER ($AC_TIMEC ==0) AND ($AC_BLOCKTYPEINFO==5002) DO _
$AC_MARKER[2]= $AC_MARKER[2] + 1
...
10.4 10.4 Actions in synchronized actions
10.4.1 Overview
General information
Actions in synchronized actions consist of value assignments, function or parameter calls,
keywords or technology cycles.
Complex executions are possible using operators.
Synchronized actions have been continually updated in several software versions for
expressions, usable main run variable and complex conditions in synchronized actions.
