Additional functions
13.6 Electronic gear (EG)
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
13-25
Programming
EGDEF(C, B, 1, Z, 1, Y, 1)
B, Z, Y influence C via setpoint
The coupling type does not need to be the same for all leading axes and must be
programmed separately for each individual master. The coupling factors are preset to zero
when the EG axis grouping is defined.
Note
EGDEF triggers preprocessing stop. The gear definition with EGDEF should also be used
unaltered when one or more leading axes affect the following axis via a curve table.
Parameters
EGDEF Definition of an electronic gear
Following axis Axis that is influenced by the leading
axes
Leading axis 1, ...5 Axes that influence the following axis
Coupling type 1, ...5 Following axis is influenced by:
0: Actual value
1: Setpoint
of the respective leading axis
13.6.2 Activate electronic gear (EGON)
Function
There are three variants for the activation command.
Programming
Variant 1:
The EG axis group without synchronization-selective will be activated with:
EGON(FA, "block change mode", LA1, Z1 ,N1, LA2, Z2, N2, ..LA5,
Z5,N5)
Variant 2:
The EG axis group with synchronization-selective will be activated with:
EGONSYN(FA, "block change mode", SynPosFA,[, LAi, SynPosLAi, Zi,
Ni])
Variant 3:
The EG axis grouping is activated selectively with synchronization. The approach mode is
specified with:
EGONSYNE(FA, "Block change mode", SynPosFA, approach mode[, LAi,
SynPosLAi, Zi, Ni])
