Transformations
7.13 Replaceable geometry axes (GEOAX)
Job planning
7-80 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
7.13 7.13 Replaceable geometry axes (GEOAX)
Function
The "Replaceable geometry axes" function allows the geometry axis grouping configured via
machine data to be modified from the parts program. Here any geometry axis can be
replaced by a channel axis defined as a synchronous special axis.
Programming
GEOAX(n,channel axis,n,channel axis,…)
or
GEOAX()
Parameters
GEOAX(n,channel axis,n,channel axis,…) Switch the geometry axes.
GEOAX() Call the basic configuration of the
geometry axes.
n Number of the geometry axis (n=1, 2 or 3)
to be assigned to another channel axis.
n=0: remove the specified channel axis
from the geometry axis grouping without
replacement.
channel axis Name of the channel axis to be accepted
into the geometry axis grouping.
