File and Program Management
3.1 Program memory
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
3-3
File types
The following file types can be stored in the main memory:
name_MPF Main program
name_SPF Subroutine
name_TEA Machine data
name_SEA Setting data
name_TOA Tool offsets
name_UFR Zero offsets/frames
name_INI Initialization files
name_GUD Global user data
name_RPA R parameters
name_COM Comment
name_DEF Definitions for global user data and macros
Description
Workpiece directory, _N_WKS_DIR
The workpiece directory exists in the standard setup of the program directory under the
name _N_WKS_DIR. The workpiece directory contains all the workpiece directories for the
workpieces that you have programmed.
Workpiece directories, identification WPD
To make data and program handling more flexible certain data and programs can be
grouped together or stored in individual workpiece directories.
A workpiece directory contains all files required for machining a workpiece. These can be
main programs, subroutines, any initialization programs and comment files.
Initialization programs are executed once as specified in the machine data
MD 11280: WPD_INI_MODE after the program selection with the first parts program start.
Example: The workpiece directory _N_SHAFT_WPD, created for workpiece SHAFT contains
the following files:
_N_SHAFT_MPF Main program
_N_PART2_MPF Main program
_N_PART1_SPF Subroutine
_N_PART2_SPF Subroutine
_N_SHAFT_INI General initialization program for the data of the workpiece
_N_SHAFT_SEA Setting data initialization program
_N_PART2_INI General initialization program for the data for the Part 2
program
_N_PART2_UFR Initialization program for the frame data for the Part 2
program
_N_SHAFT_COM Comment file
