File and Program Management
3.3 Defining user data
Job planning
3-10 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
Reserved block names
The following modules can be stored in the directory /_N_DEF_DIR:
_N_SMAC_DEF contains macro definitions (Siemens system applications)
_N_MMAC_DEF contains macro definitions (machine manufacturer)
_N_UMAC_DEF contains macro definitions (user)
_N_SGUD_DEF contains definitions for global data (Siemens system
applications)
_N_MGUD_DEF contains definitions for global data (machine manufacturer)
_N_UGUD_DEF contains definitions for global data (user)
_N_GUD4_DEF freely definable
_N_GUD5_DEF contains definitions for measuring cycles (Siemens system
applications)
_N_GUD6_DEF contains definitions for measuring cycles (Siemens system
applications)
_N_GUD7_DEF contains definitions for standard cycles (Siemens system
applications)
_N_GUD8_DEF freely definable
_N_GUD9_DEF freely definable
Note
If no measuring cycles / standard cycles are present, the modules reserved for them can be
freely defined.
1. Defining user data (GUD)
1. Save module _N_INITIAL_INI.
2. Create a definition file for user data in the Services HMI operating area
3. Load definition file into the program memory of the control
4. Activating definition files
5. Data backup
6. Creating a definition file for user data
Definition files can be prepared on the external PC or in the Services operating area.
Predefined file names also exist (also see "Reserved module names"):
_N_SGUD_DEF
_N_MGUD_DEF
_N_UGUD_DEF
_N_GUD4_DEF … _N_GUD9_DEF
Files with these names can contain definitions for GUD variables.
7. Load definition file into the program memory of the control
The control always creates a default directory _N_DEF_DIR. This name is entered as the
path in the header of the GUD definition file and evaluated when read in via the
corresponding interface.
