File and Program Management
3.5 REDEF Changing the attributes of the NC language elements
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
3-23
• Attributes of arrays cannot be set for individual elements but only always for the entire
array:
DEF CHAN INT _MYGUD[10,10]
REDEF _MYGUD INIRE // ok
REDEF _MYGUD[1,1] INIRE // not possible, alarm is output
// (array value)
• Initialization of GUD arrays themselves is not affected.
DEF NCK INT _MYGUD[10] =(0, 1, 2, 3, 4, 5, 6, 7, 8, 9)
DEF NCK INT _MYGUD[100,100] = REP (12)
DEF NCK INT _MYGUD[100,100] ;
• REDEF statements with R parameters must be enclosed in parentheses.
REDEF R[ ] INIRE
• INI attributes
Note, however, that when the INI attributes for these variables are set, that an
appropriately large memory for INIT values, can be set using MD 18150:
MM_GUD_VAL_MEM, must be available. In the machine data 11270:
DEFAULT_VALUES_MEM_MASK must be set to 1 (memory for initialization values
active). Too small a memory cause alarm 12261 "Initialization not allowed".
• R parameters and system variables
For R and system variables it is not possible to specify a default that deviates from the
compiled value. However, resetting to the compiled value is possible with INIPO, INIRE,
or INICF.
• For data type FRAME of GUD it is not possible to specify a default deviating from the
compiled value either (like for definition of the data item).
• GUD (DEF NCK INT_MYGUD)
Only the INIPO attribute is permissible for global GUD (DEF NCK INT_MYGUD).
Only the data in the corresponding channel is initialized for channel-specific GUD (DEF
CHAN INT_MYGUD) with the corresponding result (RESET, BAG-RESET or NewConfig).
Example: 2 channels are defined with the channel-specific GUD that is to be initialized
during RESET:
DEF CHAN INT _MYGUD
REDEF _MYGUD INIRE
During a RESET in the first channel, the GUD for this channel is reset and the value in
the second channel is not affected.
Setting a default value
If REDEF <name> INIRE, INIPO; INICF; PRLOC is used to change the behavior of a system
variable or GUD, the machine data DEFAULT_VALUES_MEM_MASK must be set to 1
(memory for initialization values active). Otherwise, alarm 12261 "Initialization not allowed" is
output.
