Siemens SINUMERIK 810D

Flexible NC programming
1.3 Array definitions (DEF, SET, REP)
Job planning
1-8 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
Programming
DEF CHAR NAME[n,m]
or
DEF INT NAME[n,m]
or
DEF REAL NAME[n,m]
or
DEF AXIS NAME[n,m]
or
DEF FRAME NAME[n,m]
or
DEF STRING[string_length] NAME[m]
or
DEF BOOL[n,m]
• Initialization with value lists; SET
Array definition options
DEF Type VARIABLE = SET(VALUE)
DEF Type ARRAY[n,m] = SET(VALUE, value, …)
or
DEF Type VARIABLE = Value
DEF Type ARRAY[n,m] = (value, value, …)
Note
SET is optional in the array definition.
Initializing during the program run
ARRAY[n,m]= SET(value, value, value,…)
ARRAY[n,m]= SET(expression, expression, expression,…)
• Initialization with the same values, REP
Array definition options
DEF Type ARRAY[n,m] = REP(value)
Note
Variables of type FRAME cannot be initialized.
Initializing during the program run
ARRAY[n,m] = REP(value)
ARRAY[n,m] = REP(expression)
