Page #320 background image
Transformations
7.13 Replaceable geometry axes (GEOAX)
Job planning
7-82 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
Example: geometry axis configurations for 6 channel axes
A machine has six channel axes called XX, YY, ZZ, U ,V ,W. The basic setting of the
geometry axis configuration via the machine data is:
Channel axis XX = 1st geometry axis (X axis)
Channel axis YY = 2nd geometry axis (Y axis)
Channel axis ZZ = 3rd geometry axis (Z axis)
N10 GEOAX() ;The basic configuration of the geometry axes is effective.
N20 G0 X0 Y0 Z0 U0 V0 W0 ;All the axes in rapid traverse to position 0.
N30 GEOAX(1,U,2,V,3,W) ;Channel axis U becomes the first (X), V the second (Y), W the third
;geometry axis (Z).
N40 GEOAX(1,XX,3,ZZ) ;Channel axis XX becomes the first (X), ZZ the third geometry axis (Z).
;Channel axis V stays as the second geometry axis (Y).
N50 G17 G2 X20 I10 F1000 ;Full circle in the X, Y plane. Channel axes XX and V traverse
N60 GEOAX(2,W) ;Channel axis W becomes the second geometry axis (Y).
N80 G17 G2 X20 I10 F1000 ;Full circle in the X, Y plane. Channel axes XX and W traverse.
N90 GEOAX() ;Reset to initial state
N100 GEOAX(1,U,2,V,3,W) ;Channel axis U becomes the first (X), V the second (Y), W the third
;geometry axis (Z).
N110 G1 X10 Y10 Z10 XX=25 ;Channel axes U, V, W each traverse to position 10, XX as the special
;axis traverses to position 25.
N120 GEOAX(0,V) ;V is removed from the geometry axis grouping.
;U and W are still the first (X) and third geometry axis (Z).
;The second geometry axis (Y) remains unassigned.
N130 GEOAX(1,U,2,V,3,W) ;Channel axis U stays the first (X), V becomes the second (Y),
;W stays the third geometry axis (Z).
N140 GEOAX(3,V) ;V becomes the third geometry axis (Z), which overwrites W and thus
;removes it from the geometry axis grouping. The second geometry
;axis (Y) is still unassigned.
