Path traversing behavior
9.3 Curve tables (CTAB)
Job planning
9-20 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
Parameters
General form in static or dynamic NC memory:
CTABDEL(n, m,
memType)
Deletion of the curve tables of the curve table range that
are stored in memType.
CTABNOMEM (memType)
Number of defined curve tables.
CTABFNO(memType)
Number of possible tables.
CTABID(n, memType) Outputs table number entered in memory type as the nth curve
table.
CTABLOCK(n, m,
memType)
Enable deletion and overwrite lock.
CTABUNLOCK(n, m,
memType)
Cancel deletion and overwrite lock.
CTABUNLOCK releases the tables locked with CTABLOCK. Tables,
which are involved in an active coupling, remain locked and
cannot be deleted. Lock with CTABLOCK is canceled as soon as
locking with active coupling is canceled with deactivation of
coupling. This table can therefore be deleted. It is not
necessary to call CTABUNLOCK again.
Uses of other forms Optional details for selections:
CTABDEL(n)
Delete one curve table.
Delete one curve table range.
CTABDEL(, , memType)
Delete all curve tables in the specified memory.
CTABLOCK(n)
Lock the delete and overwrite:
Curve table with number n.
CTABLOCK(n, m) Lock curve tables in the number range n to m.
CTABLOCK() All existing curve tables.
CTABLOCK(, , memType)
All curve tables in the specified memory type.
CTABUNLOCK(n)
Remove lock for the delete and overwrite: Curve table with
number n.
CTABUNLOCK(n, m) Re-enable curve tables in the number range
n to m.
CTABUNLOCK() All existing curve tables.
CTABUNLOCK(, ,
memType)
All curve tables in the specified memory type.
Uses of other forms for the diagnosis of axis couplings:
CTABID(n, memType)
CTABID(p, memType)
Outputs table number of the nth/pth curve table with memory
type memType.
CTABID(n) Outputs table number of the nth curve table with memory type
defined in MD 20905: CTAB_DEFAULT_MEMORY_TYPE specified
memory type.
CTABISLOCK(n)
Returns the lock status of the curve table with number n.
CTABEXISTS(n)
Checks curve table with number n.
CTABMEMTYP(n)
Returns the memory in which curve table
no. n is stored.
CTABPERIOD(n)
Returns the table periodicity.
CTABSEG(memType)
Number of curve segments already used in the specified memory
type.
CTABSEGID(n)
Number of curve segments used in curve table number n
