Path traversing behavior
9.4 Axial leading value coupling (LEADON, LEADOF)
Job planning
9-32 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
Programming
LEADON(FAxis,LAxis,n)
or
LEADOF(FAxis,LAxis)
or deactivate without details of leading axis
LEADOF(FAxis)
The master value coupling can be activated and deactivated both from the parts program
and during the movement from synchronized actions, see section "Motion synchronous
actions" .
Parameters
LEADON Activate master value coupling
LEADOF Deactivate master value coupling
Faxis Following axis
Laxis Leading axis
n Curve table number
$SA_LEAD_TYPE Switching between setpoint and actual value coupling
Deactivate master value coupling, LEADOF
When you deactivate the master value coupling, the following axis becomes a normal
command axis again!
Axial master value coupling and different operating states, RESET
Depending on the setting in the machine data, the master value couplings are deactivated
with RESET.
Example of master value coupling from synchronous action
In a pressing plant, an ordinary mechanical coupling between a leading axis (stanchion
shaft) and axis of a transfer system comprising transfer axes and auxiliary axes is to be
replaced by an electronic coupling system.
It demonstrates how a mechanical transfer system is replaced by an electronic transfer
system. The coupling and decoupling processes are implemented as static synchronized
actions.
From the leading axis LV (stanchion shaft), transfer axes and auxiliary axes are controlled as
following axes that are defined via curve tables.
Following axes
X feed or master value axis
YL closing or transverse axis
ZL lifting axis
U roll feed, auxiliary axis
V guide head, auxiliary axis
W greasing, auxiliary axis
