Additional functions
13.2 Check scope of NC language present (STRINGIS)
Job planning
13-6 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
Valid NC addresses without address extension with the fixed value of 400
NC addressed D, F, G, H, R and L, M, N, O, P, S, T are valid. Then
400 D as tool correction, cutting edge number (D function)
F as feed (F function)
G is defined as G code (not the path condition in this case)
H stands for auxiliary function (H function)
R is defined as system parameter and
L stands for sub-routine call-up, M stands for additional
function, N stands for sub-block,
O is free for extensions,
P stands for number of program executions,
S stands for spindle speed (S function),
T stands for tool number (T function).
Example of programmable auxiliary function T
T is defined as auxiliary function and can always be programmed.
400 = STRINGIS("T") ;Return value without address
;extension
0 = STRINGIS("T3") ;Return value with address extension
