Tables
15.1 List of statements
Job planning
15-2 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
A3
5
Tool orientation: Direction vector
component
Real s
A4
5
Tool orientation for start of block Real s
A5
5
Tool orientation for end of block;
normal vector component
Real s
ABS Absolute value Real
AC Input of absolute dimensions 0 ...,
359.9999
°
X=AC(100) s
ACC
5
Axial acceleration Real, w/o
signs
m
ACN Absolute dimensions for rotary
axes, approach position in negative
direction
A=ACN(...)
B=ACN(...)
C=ACN(...)
s
ACP Absolute dimensions for rotary
axes, approach position in positive
direction
A=ACP(...)
B=ACP(...)
C=ACP(...)
s
ACOS Arc cosine (trigon. function) Real
ADIS Rounding clearance for path
functions G1, G2, G3, ...
Real, w/o
signs
m
ADISPOS Approximate distance for rapid
traverse G0
Real, w/o
signs
m
ADISPOSA Size of the tolerance window for
IPOBRKA
Integer,
real,
ADISPOSA=.. or
ADISPOSA(<axis>
[,REAL])
m
ALF Angle tilt fast Integer,
w/o signs
m
AMIRROR Programmable mirroring (additive mirror) AMIRROR X0 Y0
Z0AMIRROR
; separate block
s 3
AND Logical AND
ANG Contour angle Real
AP Angle polar 0,..., ± 360° m,n
3
APR Read/display access protection
(access protection read)
Integer, w/o
signs
APW Write access protection
(access protection write)
Integer, w/o
signs
AR Aperture angle (angle circular) 0, ..., 360° m,n
3
