09.91 3 Operating Sequences
3.2.6 “PLAYBACK”
Extend the sofkey menu displayed and
then select the ”BLOCK SEARCH”
softkey function.
BLOCK
SEARCH
Press the RECALL key twice to return
to the ”AUTOMATIC” basic display.
• • •
Then enter block no. ”N...” of the last
block in the part program and store it
with the input key.
Operate the ”START” softkey and ...
... activate the program with the
”PROGRAM START” key.
Call up the ”AUTOMATIC” basic display
using the RECALL and ETC keys.
Then operate the ”PART PROGRAM”
and ”TEACH IN / PLAYBACK” softkeys
one after the other.
PART
PROGRAM
TEACH IN
PL.BACK
and
Continue as described above under “Sequence of operation”.
Note:
When you have set up the desired program, terminate it with M02 L
F
or M30 L
F
.
START
