3 Operating Sequences 01.93
3.2.11 ”Actual value setting” mode (”PRESET”)
The new ”actual position” and the ”PRESET offset” for the X axis are displayed.
In the same way you enter the values for the other axes, and subsequently operate the
”STORE ... AXIS” softkey after input for each.
2. ”PRESET offset” with inclusive calculation of the tool offset.
Use the same method to enter the ident no. for the other axes.
Using the keyboard, enter the number of the
desired tool offset number
D ... , into the ”offset number” input field,
and store it using the input key.
Using the keyboard, enter the identification
”Ident. No.” (see Section 3.1.3) for the X
axis, into the ”Ident no.” input field - ”2” in
the example.
Store it using the input key.
STORE
The new ”actual position” and the ”PRESET offset” for the X axis are displayed.
The displayed value ”PRESET offset” comprises:
– the entered value
– plus: the calculated tool offset.
CLEAR
PRE-OFF
You can clear all the ”PRESET offset” at
once by operating the
”CLEAR PRESET-OFFSET” softkey.
