2 Operation 11.90
2.1.1 SINUMERIK 810M operator interface with integrated machine control panel
Numeral: 7
Address for: ”Position information” X axis .....
Numeral: 8
Address for: ”Position information” Y axis .....
Numeral: 9
Address for: ”Position information” Z axis .....
Letter e
1)
Address for: ”Position information” 4th axis .....
2)
Symbol for: ”Division”
Address for: ” Program control function” @ .....
Numeral: 4
Address for: ”Interpolation parameter” I .....
Numeral: 5
Address for: ”Interpolations parameter” J .....
Numeral: 6
Address for: ”Interpolations parameter” K .....
Letter f
1)
Address for: ”Radius” U .....
Key assignment changeover:
With successive operations of this key you make either the upper or
lower symbols of the double function keys active
– yellow LED (Section 2.1.1.2) lit: lower symbols are active
– yellow LED not lit: upper symbols are active
7
X
8
Y
9
Z
4
I
@
4.
5
J
6
K
U
1) Note: These letters are not permissible for normal programming. They are used for input of, or changes to,
commands in ”CL800” Machine Code (@ . . . ).
2) Note: The 5th axis must be programmed by the extended address writing method. There is no separate key
available for the 5th axis.
2-8 © Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02
SINUMERIK 810M, GA3 (BN)
