4 Monitoring Functions 09.91
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
32
”Data format error RS232C (V.24)”
Reason:
Effect:
Remedy:
– The permissible number of decades after an address is not correct
– The decimal point occurs in the wrong place
– The part programs or subroutines are not defined or completed
correctly (check heading!)
– The NC is waiting for an ”=” character, which is not defined in EIA
code.
-Data transfer is interrupted
-The last block is not stored
Check the data to be read in.
Alarm No.
Alarm Text:
33
”Different programs same no. RS232C (V.24)”
Reason:
Effect:
Remedy:
Explanation:
The stored program and the program being read-in, have the same
program number, but are not identical.
Bock transfer: Program read in is unequal to selected program
No data are stored
Either delete or ”RENAME” the old program
Block transfer: Enter correct program number in Automatic basic
display
If a new program is read-in which has the same program number as
one already stored. Both programs are compared, and because they
are different alarm 33 is displayed.
Block transfer: The program number received is compared with the
program number entered in the Automatic basic display. If they differ
alarm 33 is displayed.
Alarm No.
Alarm Text:
34
”Operator error RS232C (V.24)”
Reason:
Effect:
Remedy:
Data transfer was started on the NC, but the PLC gave a second Start
signal.
No data are read in
Stop data input, and restart
Alarm No.
Alarm Text:
35
”Reader error RS232C (V.24)”
Reason:
Effect:
Remedy:
Error message from Siemens Tape Reader
-Data transfer is interrupted
-The last block is not stored
– Restart data transfer
– If the fault reoccurs call Service
Alarm No.
Alarm Text:
36
”BTR aborted by the computer”
Reason:
Remedy:
Part program received from BTR partner with error.
Restart
4-10
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02
SINUMERIK 810M, GA3 (BN)
