Siemens SINUMERIK 810M User Manual

01.93 4 Monitoring Functions
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
40
”Wrong data in MD 576*”
Remarks: Alarm only on commissioning
Alarm No.
Alarm Text:
41
”Error in absolute submodule”
Reason:
Explanation:
Error when using a SIPOS absolute endcoder module.
The precise type of error is shown in the “status of absolute module”
line in the “axis service data” display. The error number is displayed.
You can look up the meaning of the error number in the documentation
for the SIPOS absolute encoder module.
Alarm No.
Alarm Text:
44
"Part program memory not available"
Remarks: Alarm only on commissioning
Alarm No.
Alarm Text:
48
”PLC alarm texts from UMS illegal”
Remarks: Alarm only on commissioning
Alarm No.
Alarm Text:
87
"Illegal software limit switch"
Remarks: Alarm only on commissioning
Alarm No.
Alarm Text:
104 *
”DAC limit”
Remarks: Alarm only on commissioning
Alarm No.
Alarm Text:
108 *
”Overflow of actual value”
Remarks: Alarm only on commissioning
Alarm No.
Alarm Text:
112 *
”Clamping monitoring”
Reason:
Effect:
Remedy:
During positioning, the following error could not be eliminated faster
than the time given in machine data 156.
– NC START inhibited
– Operation will be brought to a controlled standstill
– Follow-up operation
Report the problem to Service
”
*
” stands for: ”0” = axis 1, ”1” = axis 2, ”2” = axis 3, ”3” = axis 4, ”4” = axis 5.
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EQ02 4-11
SINUMERIK 810M, GA3 (BN)
