Technical data
6
Safety
Safety class III; PELV according to EN 50178
Degree of protection accord‐
ing to EN 60529
Front side IP65
Rear side IP00
Approvals CE / cULus
Electrical data
Power consumption (without
load at USB interface)
Typically approx. 4 W
Max. approx. 5 W
Mechanical data
Dimensions Width: 483 mm Height: 310 mm Depth: 30 mm
Weight Approx. 4.4 kg
Tightening torques, max. Tension jack screws:
0.5 Nm
M3 screws:
0.8 Nm
M4 screws:
1.8 Nm
Display
Size / resolution 10.4" / 640 x 480 pixels
Backlight-service life typ. 50,000 h at 25º C (dependent on the temperature)
Note
Information about the climatic and mechanical environmental conditions is contained in the
associated section under:
"General notes and interconnection" → "Operational planning".
Operator panel front: OP 010
Manual, 07/2018, A5E36371538B 103
