Compatibility
The TCU 30.3 is compatible with the following systems (also as spare part for the TCU, TCU 20.2
and TCU 30.2):
• SINUMERIK 840D sl:
– NCU 7X0.3(B) PN (>= CNC SW 2.7 SP3 HF10)
• Or SIMATIC IPC 427E for SINUMERIK, with PCU basic software
• Or SINUMERIK PCU 50.5 (Windows XP / Windows 7)
• Operator panel fronts:
– OP 010, OP 010C, OP 010S, OP 012, OP015, OP 015A, TP015A, OP 019
Design
The TCUs are coupled via Ethernet as Thin Clients to the PCU/NCU/IPC in a dedicated subnetwork
(via DHCP server on the PCU/NCU/IPC).
Interfaces:
• 4 x USB 2.0 Hi-Speed to connect the mouse, keyboard and USB 󹪞ash drive
• Ethernet 10/100/1000 Mbit/s
The transmission rate in Ethernet system networks automatically sets itself to the maximum
possible value. 1000 Mbps can only be achieved with NCU 7x0.3B PN, IPC and PCU50.5 (if
a PCU is required).
Note
The Ethernet interface has so-called Auto MDI-X functionality. If required, the send and
receive lines of the Ethernet cable are crossed in the PHY. If, however, the partner does not
have "Autocrossover", a crossover cable is required.
Information about third-party software used
This product contains open source software. License information can be obtained via the
shortcut "License 󹪝les" on your SINUMERIK PCU desktop, or navigate to the SINUMERIK Operate
Readme OSS path "Setup/system data: System CF card/siemens/oss-license" on your SINUMERIK
NCU and read the appropriate OSS 󹪝le for this device.
Description
3.1Overview
TCU 30.3
20 Equipment Manual, 03/2023, A5E40874197B AD
