3.3 Interfaces
Overview
Function Designation Description
Double USB interface 1
1)
X203 / X204 2 x USB 2.0 Hi-Speed type A
Double USB interface 2
1)
X212 / X213 2 x USB 2.0 Hi-Speed type A
Interface for direct keys X205 2 x 10-pin plug connector
24VDC power supply X206 3-pin terminal block
I/O USB interface K1
2) 3)
X207 2 x 13-pin plug connector
LVDS display interface K2
2) 3)
X208 2 x 10-pin plug connector
LVDS display interface K3
3)
X209 2 x 10-pin plug connector
Ethernet interface X202 8-pin RJ45 socket
1)
Two of the interfaces can be loaded with 500 mA simultaneously, the other two interfaces each with
100 mA. Max. 1.2 A total.
2)
To connect to a 10" to 15" operator panel front
3)
Only to connect to an OP 019 operator panel front
The following special requirements apply to the connecting cables:
• The 24 VDC cable must be approved for temperatures up to 70° C.
• Select the permitted conductor cross-section in accordance with the national regulations
(NEC, VDE,...) from the "Power supply connectors for TCU30.3" table below. The line
protection in accordance with the national regulations (NEC, VDE,...) must be guarantied as
appropriate for the selected conductor cross-section.
• Strip the cables (7mm) for connection to the 24VDC connector plug.
• Flame resistance of the 24VDC cable according to UL 2556 VW-1/ tested according to IEC
60332-1-2.
• Observe the permissible bending radii of the cables.
• Rotate the panel only in a way that does not cause pinching of the cables.
• Route all of the cables so that they do not come into contact with cha󹪝ng edges.
NOTICE
Warning for areas subject to NEC or CEC
Safety note for connectors with Ethernet marking:
An Ethernet or Ethernet segment with all associated interconnected devices shall be located
within a single low voltage distribution network and within a single building.
The Ethernet is assigned accordingly to an "Environment A" according to IEEE802.3 or
"Environment 0" according to IEC TR 62102.
Never make a direct electrical connection to TNV lines (telephone network) or WAN (Wide Area
Network).
Description
3.3Interfaces
TCU 30.3
22 Equipment Manual, 03/2023, A5E40874197B AD
