Siemens SINUMERIK 840D Programming Manual

Special Motion Commands
5.2 Spline interpolation (ASPLINE, BSPLINE, CSPLINE, BAUTO, BNAT, BTAN)
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
5-9
3
3
3
3
3
3
3
3WR3VSHFLILHGFRRUGLQDWHV
%VSOLQH
&KHFNSRO\JRQ
C spline
In contrast to the akima spine, the cubic spline is continuously curved in the intermediate
points. It tends to have unexpected fluctuations however. It can be used in cases where the
interpolation points lie along an analytically calculated curve. C splines use third degree
polynomials.
The spline is not local, i.e. changes to an interpolation point can influence a large number of
blocks (with gradually decreasing effect).
3WR3VSHFLILHGFRRUGLQDWHV
&VSOLQHFXELFVSOLQH
3
3
3
3
3
3
3

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
