Tool offsets
8.7 Free assignment of D numbers, cutting edge numbers
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
8-37
8.7.2 Checking D numbers (CHKDNO)
Function
CKKDNO checks whether the available D numbers assigned are unique. The D numbers of
all tools defined within a TO unit may not occur more than once. No allowance is made for
replacement tools.
Programming
state=CHKDNO(Tno1,Tno2,Dno)
Parameters
state TRUE: The D numbers are assigned uniquely to the
checked areas.
FALSE: There was a D number collision or the
parameters are invalid. Tno1, Tno2 and Dno return
the parameters that caused the collision. These
data can now be evaluated in the parts program.
CHKDNO (Tno1,Tno2) All D numbers of the part specified are checked.
CHKDNO(Tno1) All D numbers of Tno1 are checked against all
other tools.
CHKDNO All D numbers of all tools are checked against
all other tools.
