Flexible NC programming
1.23 CHECKSUM: Form the checksum over an array
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
1-69
1.23 1.23 CHECKSUM: Form the checksum over an array
Function
With CHECKSUM you form a checksum over an array.
Application:
Check to see whether the initial contour has changed during stock removal.
Programming
error=CHECKSUM(VAR STRING[16] chksum, STRING[32]array, INT first,
INT last)
Parameter
CHECKSUM Form the checksum over an array
error Error variable for return
0: No error
1: Symbol not found
2: No array
3: Index 1 too large
4: Index 2 too large
5: Invalid data type
10: Check sum overflow
chksum Checksum over the array as a STRING (call-by-reference
parameter of type STRING, with a defined length of 16).
The checksum is indicated as a character string of 16
hexadecimal numbers. However, no format characters are
indicated.
Example: "A6FC3404E534047C"
array Number of the array over which the checksum is to be formed.
(call-by-value parameter of type STRING with a max. length of
32).
Permissible arrays:
1- or 2-dimensional arrays of the types
BOOL, CHAR, INT, REAL, STRING
Arrays of machine data are not permissible.
first Column number of start column (optional)
last Column number of end column (optional)
Note
The parameters first and last are optional. If no column indices are indicated, the checksum
is formed over the whole array.
The result of the checksum is always definite. If an array element is changed, the result
string will also be changed.
