Punching and nibbling
12.1 Activation, deactivation
Job planning
12-2 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
Programming
PONS G... X... Y... Z...
or
SON G... X... Y... Z...
or
SONS G... X... Y... Z...
or
SPOF
or
PDELAYON
or
PDELAYOF
or
PUNCHACC(S
min
,A
min
, S
max
, A
max
)
Parameters
PON Punching ON
PONS Punching with leader on
SON Nibbling ON
SONS Nibbling with leader on
SPOF Punching, nibbling off
PDELAYON Punching with delay ON
PDELAYOF Punching with delay OFF
PUNCHACC Travel-dependent acceleration PUNCHACC (S
min
, A
min
, S
max
, A
max
)
"S
min
" Minimum hole spacing
"S
max
" Maximum hole spacing
"A
min
" The initial acceleration A
min
can be larger than A
max
"A
max
" The final acceleration A
max
can be less than A
min
Use of M commands
By using macro technology, you can also use M commands instead of language commands:
DEFINE M25 AS PON Punching ON
DEFINE M125 AS PONS Punching with leader on
DEFINE M22 AS SON Nibbling ON
DEFINE M122 AS SONS Nibbling with leader on
DEFINE M26 AS PDELAYON Punching with delay ON
DEFINE M20 AS SPOF Punching, nibbling off
DEFINE M23 AS SPOF Punching, nibbling off
