Additional functions
13.4 Learn compensation characteristics (QECLRNON, QECLRNOF)
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
13-11
Parameters
QECLRNON (axis.1,…4) Activate "Learn quadrant error compensation" function
QECLRNOF Deactivate "Learn quadrant error compensation" function
QECLRN.SPF Learning cycle
QECDAT.MPF Sample NC program for assigning system variables and the
parameters for the learning cycle
QECTEST.MPF Sample NC program for circle shape test
Description
The traversing movements of the axes required for the learning process are generated with
the aid of an NC program. The learning movements are stored in the program in the form of
a learning cycle.
First teach-in
Sample NC programs contained on the disk of the standard PLC program are used to teach
the movements and assign the QEC system variables in the initial learning phase during
startup of the control:
Relearning
The learnt characteristics can be optimized with subsequent learning. The data stored in the
user memory are used as the basis for optimization. Optimization is performed by adapting
the sample NC programs to your needs.
The parameters for the learning cycle (e.g. QECLRN.SPF) might have to be changed for
"relearning".
• Set "Learn mode" = 1
• Reduce "Number of learn passes" if required
• Activate "Modular learning" if required and define area limits.
