Reference section
7.1
© Siemens AG All rights reserved. SINUMERIK, Manual, 5-axis machining
100
Dynamic response
Technology G groups
Look ahead
Velocity programming
DYNNORM
DYNPOS
DYNROUGH
DYNSEMIFIN
DYNFINISH
Standard dynamic response, as previously
Positioning mode, tapping
Roughing
Finishing
Smooth-finishing
G60 Exact stop at end of block
G601
G602
G603
Block change on reaching the fine in-position window
Block change on reaching the coarse in-position window
Block change at the end of interpolation
G64 Overrun of block end (LOOK AHEAD)
Smoothing
G641
G642
ADIS = … smoothing distance
ADISPOS =… smoothing distance for G0, constant velocity
Smoothing with single-axis tolerances ($MA_COMPRESS_POS_TOL[X]
= …) or ADIS, ADISPOS with intermediate blocks, constant-acceleration
(recommended)
G60, G64, G641,
G642
G code group 10
G601 – G603 Internal G code group (group 12)
G94
G93
G95
G96
Conventional block-by-block (non-modal) velocity programming in
Inches/min or mm/min
Inverse time
Inches, mm per spindle revolution
Constant cutting rate
