Siemens SIPROTEC 5 Compact Hardware Description

Input and Output Module IO060
Description
The terminals for the following are located on the input and output module IO060:
•
10 binary inputs
•
6 binary outputs (fast make contacts, type F)
The connections are on:
•
1 x 19-pole voltage terminal
i
i
NOTE
Binary inputs that are not used must be grounded.
3.2
3.2.1
Electronic Modules
3.2 Input and Output Module IO060
SIPROTEC 5 Compact, Hardware Description, Manual 33
C53000-G5300-C002-3, Edition 12.2021
